The CEM eDCM 350 (Door Control Module) is a low cost, intelligent two-door IP controller that is designed to interface to Open Supervised Device Protocol (OSDP) compliant third party smart card readers.
By utilizing RS485 serial communications with strong AES 128 encryption between the eDCM 350 controller and the OSDP compliant reader, the threat of Wiegand controller signal cloning is eliminated.
Features
– Support for two doors.
– AES128 encrypted RS485 reader communication connection.
– Supports OSDP (Open Supervised Device Protocol) v2.1.5.
– 100/10 Mbps Ethernet host Connection.
– Eight monitored inputs (four inputs per door).
– Four outputs, Two Relays (normally opened or normally closed). Two FET’S (Field Effect Transistor’s) with 12V supply.
– Self resetting fuses – saves maintenance time.Onboard LED indicators – provides visual status.
– Dedicated tamper input.
– Integrated backup battery monitoring and trickle charging.
– A supervised input can be mapped to a physical output.
